SUS430 Stage Tooling For Household Dishwasher Inner Door Metal Stamping Tooling

Brand Name : IDO

Model Number : dishwasher inner door

Certification : ISO9001

Place of Origin : China

MOQ : 1 set

Price : $10000-$50000

Payment Terms : L/C,T/T

Supply Ability : 300 sets/year

Delivery Time : 45days

Packaging Details : Wooden Case, Anti-Rust Oil, Vacuum Packaging

Part Name : Dishwasher inner door

Part Material : SUS430

Mould Type : Stage mold

Mould Size : 1500*1100*600mm

Mould Weight : 7T

Punch Tonnage : 500T

Mould Life : 1,000,000 shots

Standard Parts Brand : MISUMI

Contact Now

SUS430 Stage Tooling For Household Dishwasher Inner Door Metal Stamping Tooling

Description:

Crafted for precision and durability, our SUS430 Stage Tooling is the ideal solution for producing high-quality household dishwasher inner doors. This metal stamping tooling system is specifically engineered for SUS430 stainless steel, ensuring a perfect fit and finish for every part. It provides a reliable and efficient way to meet the demanding standards of modern appliance manufacturing.

Quick Detail:

Cycle: 6~14s (determined by product characteristics)
Punch edge sharpening: after 200,000~300,000 shots
Clearance: 10% of material thickness. The gap between the punch and die, impacting cut quality and burr.
Die Stiffness: Minimal deflection <0.01 mm. The die's resistance to bending or deformation under load.

Metal Stamping Tooling Released Commercial Components Brands:

Item		Option 1	Option 2	Option 3
1	Standard piercing punches (with or without ejectors)	MISUMI	DAYTON	FIBRO
2	Standard piercing matrix	MISUMI	DAYTON	FIBRO
3	Guide elements columns, bushes, die sets (precision plates)	MISUMI	FIBRO	DANLY
4	Sliding wear plates (bronze plus graphite)	MISUMI	FIBRO	DAYTON
5	Cam mechanisms	MISUMI	FIBRO	OMCR
6	Coil steel springs	MISUMI	FIBRO	SPECIAL SPRINGS
7	Nitrogen gas springs	MISUMI	KALLER	SPECIAL SPRINGS
8	Screws,fastener, pins, stripper bolts,	MISUMI	FIBRO	DAYTON
9	Spring guide pins, pilots, ejectors ,stock lifters, pad retainer, pilot shedders	MISUMI	FIBRO	DAYTON
10	Rotary bending mechanisms	MISUMI	DAYTON
11	Lifting elements / rotary eyebolts	MISUMI	FIBRO	DAYTON
12	Pneumatic valves and electrovalves	MISUMI	FESTO	SCHMALZ
13	Scraps pneumatic evacuator/shakers	MISUMI	FIBRO
14	Electrical connectors	HARTING	HARTING	ILME
15	Tool Steel	ASSAB	ASSAB	GROEDITZ
16	PVD Coating	OERLIKON	OERLIKON
17	Tool Bronze	AMPCO	AMPCO

SUS430 Stage Tooling For Household Dishwasher Inner Door Metal Stamping Tooling
